2016 DYNAPAC FC16000

2016 DYNAPAC FC16000
Mass (tractor) 14,000 lbs
Paver weight (incl. standard screed) 18,500 lbs
Dimensions
Basic width 8 ft
Working width, max. 18 ft
Working width, hydraulic extendable 15.50 ft
Working width, minimum (Cut Off Shoe) 1 ft
Front ramp angle 11°
Capacity
Theoretical placement capacity 600 t/h
Paving thickness (max/min) 6 in /0 in
Material hopper
Capacity 16,000 lbs
Dumping height, center 21 in
Hopper width, internal 120 in
Propulsion
Paving speed 0-140 fpm
Transport speed 3 mph
Engine
Manufacturer/Model Cummins QSB 3.3
Emissions according to EPA T3/EU3A
Rated power, SAE J1995 74 kW (99 hp ) @ 1400 rpm
Electrical system 12V
Fuel tank capacity 22 gal
Engine alternator capacity 120 Amps
Heating generator capacity 16 kW, 240V 1 phase
Undercarriage
Type Steel track with poly pad
Crawler length 72.0 in
Crawler width 12.0 in
Final drive Hydrostatic with gear reducer
Conveyor
Conveyor type Dual slat conveyor
Conveyor width 2 x 24 in
Conveyor control Automatic with Auger control
Auger
Auger diameter 9 in
Auger control Automatically with ultrasonic sensor
Extension auger 9 inches, mounted on screed extensions. Financing Available.
